• Frequency 125Khz

• Interface Weigand 26 bits

• Read range Around 100mm with ISO card

• Transponder Read only

• Power supply +12Volts linear regulated DC

• Current At 200mA typical, 300mA max.

• Indication Buzzer output with external LED

controlling

• Support cards ISO10 and compatible cards

• Decoding time Less than 100ms

• Protection Potter for environment protection

REGULAR RF CARD READER

PRO-55

• Frequency 125Khz

• Interface RS232/RS485/ Weigand 26 bits

• Read range Around 1000mm with ISO card

• Transponder Read only

• Power supply +12Volts linear regulated DC

• Current At 200mA typical, 300mA max.

• Indication Buzzer output with external LED

controlling

• Support cards ISO10 and compatible cards

• Decoding time Less than 100ms

• Protection Potter for environment protection

• User authorization : RFID card 125kHZ

• Installation : standalone

• Communication : USB 2.0

• 2 color LED indicators (red and green)

• Power : USB 5V DC max.100mA

• Device cannot be expose to atmospheric conditions

• Operating temperature : -10°C +70°C (14°F 158°F)

• Operating humidity : 10% 90%

• No need driver

• Compatible with Windows 98, 2000, XP, Vista, 7 (32bit)

• Size : 140 x 100 x 30 mm

MID-RANGE RF CARD READER

PRO-1000

USB 125Khz Desk Top Reader

USB10

Access Control Catalog

Let Us Help

#206, Sinnae Technotown

#265, Sangbong-dong,

Jungrang-gu,

Seoul

South Korea

Telephone: 82-2-34220103

Fax: 82-2-34220107

Customer Support

support@techbiotech.com

Korean Orders

orders@techbiotech.com

World Wide Sales

sales@techbiotech.com

Metal Detector Catalog

Wireless Alarm Catalog

PRODUCTS >> Access Control >> WG Readers

Passive Proximity Card

125 Khz

Passive Proximity Card

125 Khz

Passive Proximity Card

125 Khz
